Floor Drainage Systems
Surface drainage systems for indoor and outdoor
Floor drains
2023 -
| # | Art. no. | Description | Replacement for | Remarks |
|---|---|---|---|---|
| 2 | 388.125.00.1 | Geberit Fractal design grating 10 x 10 cm: Product material=Stainless steel | Stainless steel | |
| 3 | 242.408.00.1 | Geberit cover for floor drain 10 x 10 cm | Stainless steel | |
| 4 | 245.462.00.1 | Geberit frame for grating frame for floor drain 10 x 10 cm | Stainless steel | |
7 Articles
| # | Art. no. | Description |
|---|---|---|
| 2 | 245.463.00.1 | Geberit top piece with grating frame, for floor drain 10 x 10 cm |
| 2 | 242.409.00.1 | Geberit top piece with grating frame, for floor drain: Product material=Plastic |
| 4 | 170.407.00.1 | Geberit trap cup for floor drain, 10 x 10 cm |
4 Articles
| # | Art. no. | Description | Remarks |
|---|---|---|---|
| 1 | 244.079.16.1 | Geberit trap insert for collector drain, depth of water seal 50 mm: black | |
| 2 | 244.080.00.1 | Geberit section seal for collector drain, depth of water seal 50 mm: Product material=EPDM | |
| 4 | 240.405.00.1 | Geberit sleeve | Only for art. no. 388.007.00.1 |
4 Articles
| # | Art. no. | Description | Remarks |
|---|---|---|---|
| 1 | 243.999.00.1 | Geberit key for grating, lockable, 13 x 13 cm: Product material=Plastic | Only for art. no. 388.107.00.1 |
| 2 | 243.372.00.1 | Geberit top piece with grating frame and slotted grating, for Varino floor drain and floor inlet 13 x 13 cm: Product material=Plastic | |
| 2.1 | 243.371.00.1 | Geberit slotted grating for Varino floor drain and Varino floor drain 13 x 13 cm: Product material=Stainless steel | |
6 Articles
| # | Art. no. | Description | Remarks |
|---|---|---|---|
| 1 | 243.999.00.1 | Geberit key for grating, lockable, 13 x 13 cm: Product material=Plastic | For art. no. 388.107.00.1 |
| 2 | 243.372.00.1 | Geberit top piece with grating frame and slotted grating, for Varino floor drain and floor inlet 13 x 13 cm: Product material=Plastic | |
| 2.1 | 243.371.00.1 | Geberit slotted grating for Varino floor drain and Varino floor drain 13 x 13 cm: Product material=Stainless steel | |
9 Articles
| # | Art. no. | Description |
|---|---|---|
| 1 | 242.408.00.1 | Geberit cover for floor drain 10 x 10 cm |
| 2 | 243.855.06.1 | Geberit hair trap for collector drain made of PE-HD: granite grey |
| 3 | 242.134.00.1 | Seal for Geberit HDPE collector drain |
3 Articles
| # | Art. no. | Description |
|---|---|---|
| 1 | 242.135.16.1 | Trap insert for Geberit HDPE collector drain: black |
| 2 | 242.136.00.1 | Geberit section seal: Product material=EPDM |
| 3 | 242.134.00.1 | Seal for Geberit HDPE collector drain |
3 Articles
Shower floor drains
2007 - 2019
| # | Art. no. | Description | Replacement for |
|---|---|---|---|
| 1 | Go to the spare parts page: CleanPoint grating for floor-level shower | ||
| 2 | 241.671.00.1 | Geberit hair trap: Shape=Round | |
| 3 | 241.641.00.1 | Geberit top piece with grating frame, with compensation ring | 241.848.00.1 |
5 Articles
