With pneumatic flush actuation

Geberit low-height concealed cistern, 6 / 3 litres, Type 01 remote flush actuator

My list (0)

Articles

Click on the icon with the 3 dots to have more options for each item.

Replaces art. no. 109.724.21.1

Art. no.
109.724.21.2
Colour / surface

chrome / glossy

B

46.4 cm

Additional information

  • Supplied with 116.050.21.1 Type01 pneumatic actuator
  • The cistern can be operated with used water (rainwater) provided it is passed through a filter system first

Technical data

Flow pressure

0.1–10 bar

Water temperature max.

25 °C

Flush volume, factory setting

5.8 / 3 l

Product material

Plastic

Application purposes

Click on an application purpose to search more products

For drywall constructionFor installation in bathroom furnitureFor installation in part-height prewall installationsFor low level installation
For floor-standing WCsNot suitable for Geberit AquaClean AlbaNot suitable for Geberit AquaClean Sela

Characteristics

Click on a characteristic to search more products

Flush actuation pneumaticDual flushFlush pipe connection with compression jointCistern fulfils standard requirements in accordance with EN 14055, Class II
Water supply connection on the bottom leftWater supply connection 1/2”

Scope of delivery

  • Pneumatic dual-flush actuator

  • Flush bend 90°

  • Fastening material for flush pipe

  • Cup for flush volume reduction 4.0 / 2.6 l

  • Fastening material
